AD8021AR آپ آمپ اورجینال
Texas instruments شرکت سازنده
SMD نوه قراگیری بر روی برد
MSOP-8 پکیج
نویز پذیری بسیار پایین به شرح ذیل
2.1 nV/√Hz input voltage noise: نویز پذیری ولتاژ
2.1 pA/√Hz input current noise: نویز پذیری جریاان
پهنای باند ( سرعت بالا ) : 200 مگاهرتز
:توان مصرفی پایین
توان 34 میلی وات یا 6.7 میلی آمپر
ولتاژ کاری: 5 الی 24 ولت
کاربرد های مورد نظر
ADC درایورهای آنالوگ به دیجیتال
پیش تقویت کننده ابزار دقیق
ساخت فیلتر
پردازش سیگنال
و...
Low noise
2.1 nV/√Hz input voltage noise
2.1 pA/√Hz input current noise
Custom compensation
Constant bandwidth from G = −1 to G = −10
High speed
200 MHz (G = −1)
190 MHz (G = −10)
Low power
34 mW or 6.7 mA typical for 5 V supply
Output disable feature, 1.3 mA
Low distortion
−93 dBc second harmonic, fC = 1 MHz
−108 dBc third harmonic, fC = 1 MHz
DC precision
1 mV maximum input offset voltage
0.5 μV/°C input offset voltage drift
Wide supply range, 5 V to 24 V
Low price
Small packaging
Available in SOIC-8 and MSOP-8
APPLICATIONS
ADC preamps and drivers
Instrumentation preamps
Active filters
Portable instrumentation
Line receivers
Precision instruments
Ultrasound signal processing
High gain circuits
The AD8021 is an exceptionally high performance, high speed voltage feedback amplifier that can be used in 16-bit resolution systems. It is designed to have both low voltage and low current noise (2.1 nV/√Hz typical and 2.1 pA/√Hz typical) while operating at the lowest quiescent supply current (7 mA @ ±5 V) among today’s high speed, low noise op amps. The AD8021 operates over a wide range of supply voltages from ±2.25 V to ±12 V, as well as from single 5 V supplies, making it ideal for high speed,low power instruments. An output disable pin allows further reduction of the quiescent supply current to 1.3 mA.
.
.
